Low-Friction Expanded PTFE Pipe for Pneumatic Conveying Systems
Detailed Product Information: ePTFE Tubes by SUKO
Product Overview
ePTFE (expanded Polytetrafluoroethylene) tubes from SUKO offer exceptional chemical resistance, thermal stability (-200°C to +260°C), and electrical insulation. Ideal for aerospace, medical, automotive, and industrial applications, these tubes ensure reliability in harsh environments.
Key Features
- Chemical Resistance: Compatible with acids, bases, solvents, and hydrocarbons.
- Low Friction & Non-Stick: Minimal adhesion for smooth fluid/gas transfer.
- High Purity & Biocompatibility: Suitable for medical/pharmaceutical use.
- Gas Permeability: Customizable for venting or barrier applications.
- Flexible & Durable: Maintains integrity under bending or vibration.
Standard Sizes
| Item No. | Inner Diameter (mm) | Outer Diameter (mm) | Wall Thickness (mm) |
|---|---|---|---|
| 01 | 1.0 | 1.8 | 0.4 |
| 02 | 2.0 | 3.0 | 0.5 |
| 03 | 4.0 | 6.0 | 1.0 |
| 04 | 6.0 | 9.0 | 1.5 |
| 05 | 10.0 | 14.0 | 2.0 |
Custom sizes & configurations available upon request.
Technical Specifications
- Temperature Range: -200°C to +260°C.
- Pressure Rating: Up to 10 MPa (varies by size).
- Color: Natural white/translucent (custom colors optional).
Quality Assurance
- ISO 9001:2015 certified manufacturing.
- Batch-tested for consistency and performance.
Applications
- Medical: Catheters, implantable devices, sterile packaging.
- Industrial: Chemical transfer lines, seals, sensor protection.
- Electronics: Insulation for wires/cables.
- Automotive: Fuel/brake line protection.
About SUKO
SUKO specializes in high-performance polymer solutions, leveraging advanced PTFE/ePTFE technology to deliver innovation-driven products. With a global client base, we prioritize precision engineering and sustainable practices.
