UHMW Plate | Premium UHMW Polyethylene Sheet for Industry
Overview
Ultra-High Molecular Weight Polyethylene (UHMWPE) Board is a high-performance thermoplastic material known for its exceptional strength, durability, and versatility. With a molecular weight ranging from 3 to 9 million g/mol, UHMWPE offers superior properties compared to standard polyethylene, making it an ideal choice for a wide range of industrial, commercial, and specialized applications.
Key Properties
- High Wear Resistance: UHMWPE boards exhibit outstanding resistance to abrasion, outlasting many other materials in harsh environments.
- Low Friction Coefficient: The material has a self-lubricating surface, reducing friction and wear in applications involving sliding or moving parts.
- Impact Strength: Even at low temperatures, UHMWPE maintains excellent impact resistance, making it suitable for demanding conditions.
- Chemical Resistance: It is highly resistant to corrosive chemicals, acids, and alkalis, ensuring long-term performance in aggressive environments.
- Lightweight: Despite its strength, UHMWPE is lightweight, offering ease of handling and installation.
- Non-Toxic and Food-Safe: UHMWPE is FDA-approved for food contact, making it suitable for applications in the food processing industry.
- UV and Moisture Resistance: The material withstands prolonged exposure to moisture and UV radiation without degrading.
Technical Specifications
- Density: 0.93–0.96 g/cm³
- Tensile Strength: 20–40 MPa
- Elongation at Break: 300–500%
- Heat Deflection Temperature:: 85°C
- Hardness (Shore D): 60–70
- Standard Thickness: 1 mm to 200 mm (customizable)
- Standard Sizes: Available in various dimensions, such as 1000 mm x 2000 mm, or cut-to-size as per requirement.
- Colors: Natural (white), black, or custom colors upon request.
Applications
UHMWPE Boards are widely used across multiple industries due to their unique combination of properties. Common applications include:
- Industrial: Liners for chutes, hoppers, and silos; conveyor components; wear strips; and guide rails.
- Food Processing: Cutting boards, food preparation surfaces, and equipment parts due to its food-safe properties.
- Marine: Dock fenders, boat components, and other water-resistant applications.
- Medical: Prosthetic components and orthopedic implants due to biocompatibility (in specific grades).
- Automotive: Bushings, bearings, and other high-wear components.
- Construction: Protective liners and anti-slip surfaces.
Advantages
- Long service life due to exceptional durability.
- Reduces maintenance costs with low friction and high wear resistance.
- Easy to machine and fabricate into custom shapes and sizes.
- Environmentally friendly with recyclable options available.
Customization Options
We offer tailored solutions to meet specific project needs, including custom dimensions, colors, and additives for enhanced properties such as anti-static, flame-retardant, or UV-resistant features. Contact our team for detailed customization inquiries.
Installation and Maintenance
UHMWPE Boards are easy to install using standard tools and can be cut, drilled, or welded as needed. Maintenance is minimal due to the material’s resistance to wear and environmental factors. Regular cleaning with mild detergents is sufficient for most applications.
Why Choose Our UHMWPE Boards?
- Manufactured using high-quality raw materials to ensure consistent performance.
- Strict quality control processes to meet international standards.
- Competitive pricing with reliable delivery timelines.
- Expert technical support and after-sales service.
Contact Us
For more information about our UHMWPE Boards, including pricing, samples, or technical data sheets, please reach out to our sales team. We are committed to providing high-quality solutions tailored to your needs.
