Expanded PTFE Sheet, White, 1/8" – 1/32" Thick

Hello, come to consult our products !

Expanded PTFE Sheet, White, 1/8" – 1/32" Thick


Product Detail

Product Tags

Comments

Expanded PTFE Sheet is made in a process that produces a uniform and highly fibrillated microstructure with equal tensile strength in all directions. The result material is much softer and more flexible than any other form of PTFE sheet and as a gasket, conforms easily to irregular and rough surfaces. In addition, the material is easier to compress and minimizes creep and cold flow, associated with skived PTFE sheet. Expanded PTFE Sheet, will seal all aggressive chemicals over the entire 0-14 pH range except for molten alkali metals and elemental fluorine. Made from 100% virgin PTFE, and will not contaminate or discolor end products.

Expanded PTFE Sheet

Advantage:

1. High dielectric properties 2. Non-toxic3. Superb electrical insulating properties 4. A wide working temperature range from 260°C down to liquid nitrogen temperatures (-260°C) 5. Lowest coefficient of friction of any known material.6. Tremendous chemical resistance7. Limitations: low compressive & tensile strength.8. Outstanding chemical resistance9. Extremely low friction10. Soft and formable11. Good bearing and wear properties (bearing grade)12. Good weathering resistance13. Performs well at elevated temperatures14. Virgin and recycled materials available15. Any sizes available

Applications: 1. Seals and gaskets;2. Valve and fitting components;3. Pump parts;4. Manifolds;5. Semiconductor equipment;6. Scientific equipment;7. Medical equipment;8. Chemical resistant tubing;9. Capacitor dielectric;10. wire isolation;11. electrical instrument isolation.
