Our pipe extruder was accepted and sent to Shandong.
PFG150 Single Screw Extruder Features:
ü Save time and money.
ü PLC design and easy to operate.
ü Long time span. No heating effect during operation.
ü With latest technology and optimized design.
ü Min – Max Dia:20-150mm.
ü Production Per Hour: 10+ kg/h.
ü Unlimited Length
ü Automatic operation.
ü 5 Heating Zones
Technical Data：
| Type | PTFE Vertical type Ram Extruder |
| Screw | Single-Plunger |
| Automatic | Automatic |
| Computerized | Computerized |
| Plastic Processed | Sintered PTFE Powder |
| Machine with PTFE Tube Mould | Mould Depends on Required |
| Process | Extruder M/c |
| Power KW | 15 |
| Tube OD Size range | 25-150 mm |
| Tolerance THK | 0.1 – 0.2 mm |
| Tolerance OD | 0.1mm-.05mm |
| Length | Unlimited |
| Production Per Hour in Kg | 8-12 |
| Electricity Consumption Per hour | 1.2 |
| Temperature zone | 3-6 |
| Compressive force [kN] | 100 – 600 |
| Weight of the Machine | 1320 |
| High of the Machine mm | 2580 |
| Floor area of the Machine M2 | 3.5 |
| Warrenty for Parts | 1 Year |
| Machine Gurantee Period | 1 Year |
| Free Spares | 1 sets |
| Floor Hole Dia mm | 300mm |
| Frame inside size L*W | 660*660mm |
| Frame Outside size L*W | 820*820mm |
| Voltage/PH/Hz | AC380V 50Hz 3 Phase |
Post time: Mar-10-2018
