PTFE Tube Ram Vertical Type Extruder PFG150 Dia 20mm-150mm
PTFE Plastic Tube Extrusion 105
PFG150 Single Screw Extruder Features:Vertical Ram Extruder for PTFE tube;Ram extruding machine for PTFE tube;Using for Pre-sintering PTFE material;Suit for new PTFE material or Recycle PTFE material;Rangeof diameter PTFE Extrusion 20-150 mm, Heating zones 5 zones; Automatic.
PFG150 Single Screw Extruder Features:
ü Save time and money.
ü PLC design and easy to operate.
ü Long time span. No heating effect during operation.
ü With latest technology and optimized design.
ü Min - Max Dia:20-150mm.
ü Production Per Hour: 10+ kg/h.
ü Unlimited Length
ü Automatic operation.
ü 5 Heating Zones
Product Description- RAM Extruder For PTFE Tube(Φ20-150mm)
Sunkoo PFG150 Tube Extruder is to extrude PTFE/UHMWPE Tubes. It is designed using latest technology, fully reliable and easy to operate for customers. Performance in terms of production and working hour capacity is competitive to other machines. Low maintenance is required , giving high production in market.
PFG150 Single Screw Extruder Features Include:
1.Vertical Ram Extruder for PTFE Tubes
2.Ram extruding machine for PTFE Tubes.
3.Using for Pre-sintering PTFE material.
4.Suit for new PTFE material or Recycle PTFE material.
5. Adjustable Heating zone: 5 zone area
6. Long service life through solid workmanship and use of high quality components.
7. Measurement transducer like pressure, force and ram speed for permanent control of the extrusion process and extrusion speed.
8. Measuring and controlling system for constant extruder speed
9. Low space requirement through vertical construction
10.Operating through touch screen and recording of the extrusion process parameters
1. Save time and money, good advantage price offer to customers.
2. Intelligent and easy-to-use operations.
3. Small workplace required due to its compact design and electricity saving machine.
4. Super quality output and the physical properties is adjustable.
5. Precise temperature control, reaches + -1 degree.
6. Long- life, with modern technology and optimized design.
|Type||PTFE Vertical type Ram Extruder|
|Plastic Processed||Sintered PTFE Powder|
|Machine with PTFE Tube Mould||Mould Depends on Required|
|Tube OD Size range||25 - 150 mm|
|Tube THK Size range||1.5 - 35 mm|
|Tolerance THK||0.1 - 0.2 mm|
|Production Per Hour in Kg||8-12|
|Electricity Consumption Per hour||1.2|
|Compressive force [kN]||100 - 600|
|Weight of the Machine||1320|
|High of the Machine mm||2580|
|Floor area of the Machine M2||3.5|
|Warrenty for Parts||1 Year|
|Machine Gurantee Period||1 Year|
|Free Spares||1 sets|
|Floor Hole Dia mm||300mm|
|Frame inside size L*W||660*660mm|
|Frame Outside size L*W||820*820mm|
|Voltage/PH/Hz||AC380V 50Hz 3 Phase|
